Pixhawk 6C Plastic
Holybro Pixhawk 6C is a Pixhawk-family flight controller with an integrated baseboard: compute, sensors and connectors in one housing, ordered as a single part number. This is the plastic-cased version — lighter and lower cost than the aluminium one, and the usual choice on a small aircraft with an uncrowded electronics bay.
Click to enlargeFree delivery anywhere in IndiaUsually within 2 weeks. The date is confirmed on your quote.
SKU 11054
Nothing to pay now. We reply within one business day with a quotation at this price and a delivery date.
- Part number
- 11054
- Category
- Autopilot Flight Controllers
- Type
- Flight controller
Pixhawk 6C Plastic price in India
| Options & SKU | Price | Add or enquire |
|---|---|---|
Standard11054 | ₹29,013.79 | Enquire about Standard |
Prices are in rupees and include GST and delivery anywhere in India. Delivery usually takes up to two weeks, and your quotation gives the exact date.
At a glance
You may also need
Used for
- Multirotor, fixed-wing and rover platforms needing a complete autopilot with a fixed connector set and no separate baseboard to specify
Specifications
| Model | Pixhawk 6C |
| Manufacturer | Holybro |
| Holybro SKU | 11054 |
| Product type | Flight controller |
| Product line | Pixhawk 6C (integrated baseboard) |
| Category | Autopilot Flight Controllers |
| Processor | STM32H743, Cortex-M7, 480 MHz, 2 MB flash, 1 MB RAM |
| I/O processor | STM32F103 / Cortex-M3 / 72 MHz / 64 KB SRAM |
| IMU | ICM-42688-P, BMI088 |
| Magnetometer | IST8310 |
| Barometer | MS5611 |
| PWM outputs | 16 (8 I/O + 8 FMU) |
| Serial ports | 3 |
| Flow control on | TELEM1, TELEM2 |
| GPS ports | 2 |
| I2C ports | 1 |
| CAN ports | 2 |
| Analog power inputs | 2 |
| Autopilot power input | 6 V maximum |
| USB input | 4.75-5.25 V |
| Servo rail (pass-through, not a supply input) | 0-36 V |
| Dimensions | 84.8 x 44 x 12.4 mm |
| Baseboard | Integrated |
| Case | Plastic |
| Mass | 34.6 g |
| Operating temperature | -40 to 85 °C |
Works with these accessories
Analog power modules such as the PM02 V3, Holybro M10 and H-RTK GNSS receivers, SiK telemetry radios. The aluminium-cased 6C is the same controller in a different housing.
Questions buyers ask
What is the Pixhawk 6C Plastic price in India?
₹29,013.79. Delivery anywhere in India is included in that price.
How big is it?
84.8 x 44 x 12.4 mm.
Can I get the datasheet and drawings?
Yes. Ask when you request a quote and we will send the manufacturer's datasheet and any drawings we have.
Can I return it?
Yes, within 30 days of delivery, if it is unused and in its original packaging. You pay the return shipping, and we refund 90% of the price after checking the part.
How do I order this in India?
Vebix Automation is an authorised Holybro distributor in Pune and delivers across India. Add it to your cart, or request a quote with the option and quantity. We reply within one business day with a quotation at the listed price and a delivery date, usually within two weeks.
Compare with similar autopilot flight controllers
The manufacturer’s figures for this part and the ones most like it, side by side.
| Product | Product line | Processor | IMU | Magnetometer | Barometer |
|---|---|---|---|---|---|
| Pixhawk 6C Plastic this page | Pixhawk 6C (integrated baseboard) | STM32H743, Cortex-M7, 480 MHz, 2 MB flash, 1 MB RAM | ICM-42688-P, BMI088 | IST8310 | MS5611 |
| Pix32 V6 Mini Baseboard | — | — | — | — | — |
| Pix32 V6 Standard Baseboard | — | — | — | — | — |
| Pix32 v6 | Pix32 v6 (separate baseboard required) | STM32H743, Cortex-M7, 480 MHz, 2 MB flash, 1 MB RAM | ICM-42688-P, BMI088 | IST8310 | MS5611 |
| Pixhawk 6C Aluminum | Pixhawk 6C (integrated baseboard) | STM32H743, Cortex-M7, 480 MHz, 2 MB flash, 1 MB RAM | ICM-42688-P, BMI088 | IST8310 | MS5611 |
| Pixhawk 6C Mini Model-A | Pixhawk 6C Mini (integrated baseboard) | STM32H743, Cortex-M7, 480 MHz, 2 MB flash, 1 MB RAM | ICM-42688-P, BMI088 | IST8310 | MS5611 |
